型号：NS 5.75 1P(solid block without hole)
产品描述 | |
| 型号/Part No.: | NS 5.75 1P(solid block without hole) |
| 间距/Pitch: | 5.75 |
| 位数/Poles: | 1P |
| 料号/Number: | NS0100x10000G |
详细信息请参阅pdf文件 | 网站图纸仅供参考，具体需求请联系业务。 |
产品介绍
电气性能-Electrical
| 安规类别/Safety category: | cULus |
| 额定电压/Voltage rating: | 150V |
| 额定电流/Current rating: | 7A |
| 适用线经/Wire range: | |
| 单芯线经（AWG）/Solid wire(AWG): | 18-22 |
| 多芯线经（AWG）/Stranded wire(AWG): | |
| 剥线长度/Wire strip length: | 5~6mm |
| 耐电压值（1分钟）/Withstanding Voltage: | 1.3 KV |
| 安全认证/Safety Approval: |  |
| 操作温度/Operating temperature: | -40℃ to +115℃ |
| 焊锡温度/Soldering temperature: |
产品料号编码原则-How to order
|
|
|
- 01:1 Poles
- 0 5.75/.0.227
- 0 Black
2 Red
5 Green
8 Grey
8 White - 1 Solid block without hole
- 0000 Standard
Any special item by customer request,please contact sales department - G RoHS compliant
(lead<4%)
In copper A lloy
