Materials
Pin                            :Brass,  CuZn38pb2
Plating(Sleeve)         :Tin plated over Brass & Nickel.
                                 Or 3 u" Gold Plated over Brass
Special Plating         :see table on"Pin&Clip Plated Code"
Insulator body         :FR-4 or PPS, UL94V-O


Electrical
Maximum current :              1A
Insulation resistance :          ≧10000MΩ  at 500VAC
Rated  voltage  :                  100 VRMS /150VDC
Air and creepage distance : 0.6mm
Capacitance:                         0.3pF max

Mechanical
Operating temperatures (continuous):
Gold plated  :-55℃to+125℃
Tin plated    :-40℃to+105℃
Environmental data

 Solderability (IEC 60068-2-20. Ta)  :235  C, 2s
Resistance to soldering heat  (IEC 60068-2-20.  Tb) :
- Through hole mount components     :260  C,  10s
