Materials
Pin                            :Brass,Screw Machined
Outer Sleeve            :CuZn38pb2
Inner Clip                  :Beryllium Copper,heat treated
(Contact 6-finger)
Plating(Sleeve)         :Tin plated over Brass & Nickel.
                                   Or 3 u"  Gold Plated over Brass
Plating(Clip)               :Gold Flash plated over Nickel
Special Plating           :see table on"Pin&Clip Plated Code"
Insulator body            :FR-4 or PPS. UL94V-O

 Electrical
Maximum current :1A
Contact resistance per contact :<4mΩ

Insulation resistance :          ≧10000MΩ at  500VAC
Rated  voltage  :                  100 VRMS /150VDC
Air and creepage distance : 0.6mm
Capacitance:                        0.3pF max

Mechanical
Average insertion force with steel pin ofΦ 0.38mm/.015" :< 60g
Average withdrawal force with steel pin ofΦ 0.38mm/.015": ≧15g
Mechanical life cycle : 200 time /minimum
Operating temperatures (continuous):
Gold plated                :-55 ℃ to+125℃ 
Tin plated                  :-40 ℃ to+105 ℃ 
Features:
               1.Low insertion force socket with 6fingers contacts
               2.Closed end construction for 100% anti-wicking of solder

Application
Environmental data
Solderability (IEC 60068-2-20. Ta)  :235 ℃  , 2s
Resistance to soldering heat  (IEC 60068-2-20.  Tb) :
-Through hole mount components     :260 ℃  ,  10s
