Materials
Insulator body material :PPS.  UL94V-O
Pin (outer sleeve) :Brass,CuZn38Pb2,machined QQ-B626D MIL-5-83505
Plating pin :
Tin plated; min,2 u m nickel+min 4 um tin QQ-N-209 MIL-T-10727 Type
1 Gold plated : min,2 um nickel+0.25 um full gold QQ-N-290 MIL-G-4520 4B

Electrical

Maximum current :              1A
Insulation resistance：        ≧10000MΩ at 500VAC
Rated  voltage  :                   100 VRMS /150VDC
Air and creepage distance : 0.6mm
Capacitance:                         0.3pF max

Mechanical
Operating temperature range
Gold plated version : -55℃to+125℃continuous
Tin plated version :-40℃ to+105℃ continuous
Max.soldering temperature without damage :260℃,10 seconds
Solderabiliy :IEC 68-2-20 MIL-202 M208
Shock :Electrical discontinuities and Other damage noted after acceleration
of 10X200g :<50ns,IEC 68-2-27 MILSTD 202E no other damage
Vibration :Electrical discontinuities and damage noted after vibration with
10-2000Hz,20g Ih : <50ns,IEC 68-2-6 MIL-S-83505 no other damage
Resistance against detergents :IEC 68-2-45
Polarization :A slight curve on the top left-hand corner of the socket body

Application

Solderability (IEC 60068-2-20. Ta)  :235  C, 2s
Resistance to soldering heat  (IEC 60068-2-20.  Tb) :
-Through hole mount components     :260  C,  10s
