Materials
Insulator: Glass filled Hi-temperature thermoplastic UL 94V-0
Receptacle contact:
Sleeve: brass ,gold or tin-lead plated over  2-3um nickel
Clip:  Stamped beryllium-copper,gold or tin-lead plated over
         2-3um nickel.

Electrical
Rated current(A):1
Rated voltage: 50 VRMS / 75VDC
Max contact resistance(m Ω: 20mΩ
Insulation resistance:10000MΩ  after climatic tests)
Dielectric strength: 500VRMS
Air and creepage (min): 0.4/0.5
Capacitance(pF): 1

Mechanical
Gauge diameter(mm):0.38
Insertion force(N):0.6
Withdrawal force(N):0.2
Mechanical life:  min. 200

Environmental
Operating temperature: -55℃ to +125℃

 Vibration(10-2000Hz,15g): no electrical discontinuity>1us
Shock:(50g): no electrical discontinuity>1us
Solderability (IEC 60068-2-20. Ta)  :235  C, 2s
Resistance to soldering heat  (IEC 60068-2-20.  Tb) :
-Through hole mount components     :280  C,  10s
