Materials
Insulator: Glass filled Hi-temperature thermoplastic UL 94V-0  colour black.
Pin :  brass .gold or tin-lead plated over 2-3um nickel

Electrical
Rated current(A):1
Rated voltage: 50 VRMS / 75VDC

Insulation resistance:10000MΩafter climatic tests)
Dielectric strength: 500VRMS
Air and creepage(min): 0.4/0.5
Capacitance(pF): 1

Mechanical
Operating temperature: -55℃ to +125℃

Vibration(10-2000Hz,15g): no electrical
                                           discontinuity>1us
Shock:(50g): no electrical discontinuity>1us

Application
Solderability (IEC 60068-2-20. Ta)  :235  C, 2s
Resistance to soldering heat  (IEC 60068-2-20.  Tb) :
-Through hole mount components     :280  C,  10s
