产品介绍

电气性能-Electrical

安规类别/Safety category:	UL VDE CQC
额定电压/Voltage rating:	300V 450V 450V
额定电流/Current rating:	10A 10A 24A
适用线经/Wire range:	0.34~4.0mm²0.2~2.5mm²
单芯线经（AWG）/Solid wire(AWG):	12-22
多芯线经（AWG）/Stranded wire(AWG):	12-22
最大锁紧扭力/Torque:	3.5Lb-In 0.4N.m 0.4N.m
螺丝规格/Screw:	M2.5
剥线长度/Wire strip length:	6~7mm
耐电压值（1分钟）/Withstanding Voltage:	1.6KV 2KV 2.5KV
安全认证/Safety Approval:
操作温度/Operating temperature:	-40℃ to +115℃
焊锡温度/Soldering temperature:	260℃ ±5℃ /5Sec

产品料号编码原则-How to order

XX
Poles

X
Pitch

X
Screw&Clamp

X
Color

End stackable
02 2 contacts
03 3 contacts
… …
16 16 contacts
(pitch:7.5)
08 08 contacts
(pitch:15.0)
2 7.5/.295"
3 15.0/.5906"
0 "-/+"Combination type
W/Brass Machined Clamp
1 "-"Slot type
W/Brass Machined Clamp
4 "-/+"Combination type
W/Steel Stamping Clamp
5 "-"Slot type
W/Steel Stamping Clamp
COLOR
0 Black (RAL9005)
2 Red (RAL3001/D)
3 Orange(RAL2011/P)
4 Yellow(RAL1018/A)
5 Green(RAL6018/T)
6 Blue (RAL5015/A)
8 Grey(RAL7035/D)
9 White(RAL1102)
C Green(RAL6018/U)
0 Stackable
A Solid block
(Only 5.0 & 7.62 pitch)
000 0 Standard

Any special item by customer request,
please contact sales department.
G RoHS compliant
(lead<4%)
In copper A lloy

H RoHS compliant
(lead<1000ppm)
In copper A lloy
